Mail Mirror on NAS

Linux, Tech
~6 minutes

The problem

In the past, I used to mirror my email accounts locally and use Notmuch with the alot email client. Every email was tagged appropriately, I would only see the tags I wanted in alot and it was generally a pretty smooth system that got me very, very close to inbox zero.

The problem was that this was only the case on my desktop PC. Every time I was out of the house or wanted to try out a new distro, the email I would see anywhere else was still a cluttered mess as the tagging was only local to that one machine.

The solution

  1. Move from Notmuch tags to folders
  2. Move the email mirroring off my main PC
  3. (bonus) Get Notmuch back, but not locally

My NAS is by definition always on and - should I want - I can access it from anywhere in the world (though the setup I chose doesn't depend on this at all). This also provides me with a place to keep backups of email that I might need in the future, but serve no purpose taking up space on my email provider's drive.

So, with a solution planned, let's get started.

Part 1: Move from Notmuch tags to folders

Tags are great, but we want every client to have access to organised email, so IMAP folders are the way to go here. IMAPFilter is a pretty well-established tool for moving email around on IMAP servers; it provides a good amount of filter options for selecting those emails and the fact that its configuration is done in Lua allows us to customise the procedure anyway we like.

Installing IMAPFilter

Since this is going to run on my NAS, a Docker container is the obvious way to go.

I've prepared a Docker image for IMAPFilter. Normally, I would use Alpine Linux as a base, but IMAPFilter is not yet in a stable release of Alpine (it's in edge, so it should happen eventually), because of this, the Docker image uses Debian as a base. This doesn't affect its use, but is good to know.

This image is set up to be able to run IMAPFilter on a schedule. Now, IMAPFilter can stay connected to all defined IMAP accounts and listen for either RECENT or EXISTS events, which normally indicate that new mail has arrived. In theory, this would be the ideal way to run as we wouldn't have to keep polling the email server(s) and could just run our filters when needed. Unfortunately, many email providers only send these events once and only to one connected client, meaning IMAPFilter wouldn't get the notification if, for example, my email client on Android also happened to be connected at the time.

Instead, I'm using Supercronic to schedule IMAPFilter to be run every few minutes. I also set flags on messages that have already been seen by IMAPFilter so we don't have to check all mail in the inbox every time, but that's a setup detail for later.

I'm using the following crontab setup. You may chose to run less often, if you get less promotional email than I do:

# Run every 2 minutes, starting from 0
0/2 * * * * /workdir/sync.sh imapfilter

The /workdir/sync.sh script can just be export IMAPFILTER_HOME=/workdir/.imapfilter; imapfilter -c /workdir/.imapfilter/config.lua, but we'll return to that later.

Create two bind mounts for Docker, mounting the crontab to /etc/crontab and your configuration directory to /workdir/.imapfilter:

docker run -d \
  --name mail-imapfilter \
  --mount type=bind,source="/path/to/your/confs/crontab",target=/etc/crontab,readonly \
  --mount type=bind,source="/path/to/your/confs/imapfilter",target=/workdir/.imapfilter,readonly \
  cybolic/imapfilter-isync:latest

This command is just to test and give a quick overview. Ideally you wouldn't run the docker command like this, but use a docker-compose.yml file or something like Portainer instead.

Setting up IMAPFilter's filters

IMAPFilter filters are usually written directly in Lua, but I like to keep my data separate from my code and filter definitions definitely fall under data for me. Instead, I wrote a small module that lets me write filters as Lua tables instead of code. This allows me to write some things more succinctly and also opens up the possibility to write an exporter for the filter rules, should I move away from IMAPFilter down the line.

Here's the module and here's an example of how I use it:

messages = messages - rulesrunner.run_rules(messages, {
  -- PayPal Subscription receipts
  { subscription_paypal = {
    { match_subject = 'receipt.*to Dropbox' },
    { match_subject = 'receipt.*to Humble Bundle', contain_body = "Humble Choice" }
  }, from = { contain_from = '@paypal' }, move_to = 'Official/Receipts/Subscription' },
  -- Google Play Subscription receipts
  { subscription_googleplay = {
    { contain_subject = 'receipt' },
    { contain_body = 'subscription' }
  }, from = { contain_from = 'Google Play', contain_subject = 'Your Google Play' }, move_to = 'Official/Receipts/Subscription' },
  -- Game purchases
  { purchase_games = {
    { contain_from = "@steampowered.com", contain_subject = { "Steam purchase", "thank you" } }
  }, move_to = 'Official/Purchase/Games' },
  -- Crowdfunding direct messages
  { crowdfunding_messages = {
    { contain_from = '@kickstarter.com', match_utf8_field = { 'subject', 'response needed|sent you a message|new message' } }
  }, flag = true }
}, accounts.posteo)
  • Each rule in the main table passed to run_rules is run in order and given the messages table with any results from previous rules subtracted.
  • Each filter (e.g. match_subject) is logically ANDed with the rest in the rule.
  • Multiple filters of the same type can be defined by providing their values in a table (e.g. contain_subject = { "Hello", "World" }) and are ANDed.
  • Filters that take more than one argument (like match_field and match_utf8_field) have their arguments defined in a table.
  • Two custom matchers, match_utf8_field and match_utf8_body decode Base64-encoded UTF8 text before matching (necessary for a lot of modern email).
  • The move_to key triggers moving the matches to the given destination (the account to move to is given in the final argument to run_rules). delete and flag are also supported.
  • The returned value is a table of all matches so I can subtract them from messages so the next run_rules block skips them.

If you want to do the same filtering without my module, this would be the code for just the PayPal example above:

local results
local subresults
-- PayPal Subscription receipts
local _messages = messages:contain_from('@paypal')
-- for Dropbox
subresults = _messages:match_subject('receipt.*to Dropbox')
_messages = _messages - subresults
results = Set(subresults)
-- for Humble Choice
subresults = _messages:match_subject('receipt.*to Humble Bundle') * _messages:contain_body("Humble Choice")
_messages = _messages - subresults
results = results + subresults
results:move_messages(accounts.posteo['Official/Receipts/Subscription'])

Personally, I find the table version easier to read.

At the end of the filtering, I add a filtered flag to all messages that were matched so they aren't processed next time IMAPFilter runs:

results:add_flags({ 'Filtered' })

And I get the initial list of messages to process as so (messages from the last 24 hours that haven't been processed):

local messages = (accounts.posteo.INBOX:is_newer(1) + accounts.gmail.INBOX:is_newer(1)):has_unkeyword('Filtered')

You can find my full setup and rules here. Do note that this is the first time I've written anything in Lua, so this setup is not necessarily production quality, but it works for my use. The files in that repo are also not the exact ones I use on my NAS; these are my local dotfiles for my main PC, so consider it more of a staging area.

Part 2: Move the email mirroring off my main PC (setting up isync / mbsync)

The Docker image used above also has isync (also known as mbsync) installed, so we can just throw a config file in there and add it to the crontab.

I've set this up to do the synchronisation in stages:

  • Every 2 minutes: The inbox gets synced
  • Every 7 minutes: Sync mail sorted by IMAPFilter into folders that I care about every
  • Every 15 minutes: A full sync of all email

You'll see that IMAPFilter runs every two minutes (:00, :02, etc.) and isync runs every 2 + 1 minutes (:01, :03, etc.). This gives IMAPFilter time to sort the email before isync fetches it.

mbsyncrc:

# Generic defaults

Create Slave
SyncState *
CopyArrivalDate yes


# Accounts

IMAPAccount posteo
CertificateFile /etc/ssl/certs/ca-certificates.crt
SSLType IMAPS
Host posteo.de
User username@posteo.net
PassCmd /workdir/get_passwd.sh posteo

IMAPStore posteo-remote
Account posteo

MaildirStore posteo-local
# The trailing "/" is important
Path /workdir/data/posteo-account/
Inbox /workdir/data/posteo-account/inbox
Subfolders Verbatim


# Channels

Channel posteo-inbox
Master :posteo-remote:INBOX
Slave :posteo-local:inbox
Sync All

Channel posteo-sorted
Master :posteo-remote:
Slave :posteo-local:
Patterns * !archived !drafts !sent !trash !Inbox !"Unimportant*" !"Official/Backups*" !"Promotional*"
Sync All

Channel posteo-non-urgent
Master :posteo-remote:
Slave :posteo-local:
Patterns "Unimportant*" "Official/Backups*" "Promotional*"
Sync All

Channel posteo-archived
Master :posteo-remote:Archived
Slave :posteo-local:archived
Sync All

Channel posteo-sent
Master :posteo-remote:Sent
Slave :posteo-local:sent
Sync All

Channel posteo-drafts
Master :posteo-remote:Drafts
Slave :posteo-local:drafts
Sync All

Channel posteo-trash
Master :posteo-remote:Trash
Slave :posteo-local:trash
Sync All


# Groups

Group inbox
Channel posteo-inbox

Group sorted
Channel posteo-inbox
Channel posteo-sorted

Group full-without-inbox
Channel posteo-non-urgent
Channel posteo-drafts
Channel posteo-sent
Channel posteo-trash
Channel posteo-archived

crontab:

# Run every 2 minutes, starting from 0
0/2 * * * * /workdir/sync.sh imapfilter
# Run every 2 minutes, starting from 1
1/2 * * * * /workdir/sync.sh isync inbox

# Run every 7 minutes
*/7 * * * * /workdir/sync.sh isync sorted

# Run every 15 minutes
*/15 * * * * /workdir/sync.sh isync full-without-inbox

sync.sh:

#!/usr/bin/env bash

if [[ "$1" = "isync" ]]; then
  mbsync --config /workdir/.mbsyncrc $2
elif [[ "$1" = "imapfilter" ]]; then
  export IMAPFILTER_HOME=/workdir/.imapfilter
  imapfilter -c /workdir/.imapfilter/config.lua
fi

Our Docker setup should now look something like this:

docker run -d \
  --name mail-imapfilter \
  --mount type=bind,source="/path/to/your/confs/crontab",target=/etc/crontab,readonly \
  --mount type=bind,source="/path/to/your/confs/imapfilter",target=/workdir/.imapfilter,readonly \
  --mount type=bind,source="/path/to/your/confs/mbsyncrc",target=/workdir/.mbsyncrc,readonly \
  --mount type=bind,source="/path/to/your/email/storage",target=/workdir/data \
  cybolic/imapfilter-isync:latest

Part 3: Get Notmuch back, but not locally

Even though I'm no longer using Notmuch to sort my email, that doesn't mean it's not still a great program for very quickly searching one's email. Since Notmuch reads through all the email files, it's not really something you'd want reading the files over a networked connection to your NAS. Instead, it's much faster to run an instance of Notmuch on your NAS, let that create it's database and then let your local Notmuch instance just use that database.

For that, I've created another Docker image, cybolic/notmuch. Just like the previous one, it uses Supercronic, so you can set it up to run Notmuch every 30 minutes or so, depending on how fresh you want your search results.

Dockerfile:

docker run -d \
  --name mail-imapfilter \
  --mount type=bind,source="/path/to/your/confs/crontab",target=/etc/crontab,readonly \
  --mount type=bind,source="/path/to/your/confs/notmuch",target=/workdir/notmuch-config,readonly \
  --mount type=bind,source="/path/to/your/email/storage",target=/workdir/data \
  cybolic/notmuch:latest

crontab:

# 15 and 45 past
15/30 * * * * notmuch new

notmuch-config:

[database]
path=/workdir/data

[user]
name=Christian Dannie Storgaard
primary_email=address@host.com
other_email=semicolon@separated.com;list@of.com;other@addresses.com

[new]
tags=new
ignore=/[.]*.(off|old|bak)$/;/[.]*.json$/;.lock;/.*[.]mbsyncstate.*$/;.uidvalidity

[search]
exclude_tags=deleted;spam;trash;

[maildir]
synchronize_flags=true

[index]
headers.List=List-Id

Everything will just work as long as your local Notmuch config file's path variable points to the same files as your NAS instance uses. My email storage is mounted using NFS, so is set to /mnt/nas-mail in the local Notmuch config.

That's it! Your email is now sorted, backed up, searchable and available from your NAS.
